SF-101DDirect-Drive Industrial Blindstitch Machine
The SF-101D is an industrial blind stitch sewing machine for hems intended to remain concealed on the visible fabric face. Direct drive and single-thread chainstitch formation support the selected blind-hemming operation.
Compare this model with the desktop and industrial blindstitch range, or use our machine selection enquiry guide to prepare your requirements.
SAFE catalogue product imageProduct advantages
Details that support the operation.
- 01Direct-drive motor arrangement.
- 02Single-thread chainstitch with an arc-action looper mechanism.
- 03Skip-stitch settings of 1:1 and 2:1.
- 04Automatic trimming, positioning and foot lifting are optional configurations.
Applications & sewing operations
Review it against your production task.
- Trouser hems and cuffs.
- Shirt and suit-component hemming.
- Cotton, wool and synthetic materials within the listed medium-to-heavy range, following sample review.
Send your material and intended seam for configuration review. Optional functions and attachments should be confirmed in the quotation.
Technical data
Specifications.
Specifications follow the reviewed SAFE v06 catalogue. Confirm your final machine configuration in the quotation.
| Specification | Details |
|---|---|
| Maximum speed | 2,500 stitches/min |
| Skip-stitch settings | 1:1 / 2:1 |
| Needle type | LW×6T #11 / #14 |
| Stitch formation | Single-thread chainstitch |
| Drive | Direct drive |
| Material range | Medium to heavy |
| Packing dimensions | 580 × 435 × 350 mm |
| Net / gross weight | 25 / 30 kg |
Before you choose
Questions about this machine.
Is automatic thread trimming included?
The catalogue identifies trimming, positioning and presser-foot lifting as optional functions. Please specify them when requesting your configuration.
Is this the desktop SF-500 blindstitch machine?
No. This page is for the industrial SF-101D. The desktop SF-500 in the same catalogue section is a separate machine.
How should I choose a blind-hem sewing machine for my fabric?
Send the fabric, folded hem and required face appearance. An industrial blind hemming machine needs an appropriate needle, penetration setting and material handling. Assess the visible result on the actual fabric before confirming the setup.
