Home / Sewing Machines / SF-V99-D4
SAFE · Lockstitch
SF-V99-D4 Computerized Lockstitch Sewing Machine
The SAFE SF-V99-D4 computerized lockstitch sewing machine combines direct drive with automatic backtacking and presser-foot lifting. Its listed 0–5 mm stitch length and maximum 5,000 rpm speed suit buyers comparing garment straight-stitch stations.
Product features
Built around the sewing operation.
- 01Automatic backtacking supports reinforcement at the beginning and end of the seam.
- 02The D4 version adds automatic presser-foot lifting to the sewing functions described for D3.
- 03The catalogue includes decorative stitching for light and heavy fabrics; suitability depends on the selected needle, thread and material.
- 04Direct-drive operation and a 0–5 mm stitch-length range are listed for this configuration.
Applications & catalogue details
Check the material, seam and handling.
- Garment assembly with straight lockstitch seams.
- Repeated seams that need backtacking and frequent presser-foot lifting.
- Decorative or reinforcement work after checking the required stitch against a sample.
Send a material or finished-seam sample to confirm the configuration. Catalogue examples illustrate the operation; the required result should be agreed before ordering.
Discuss Your Application
Technical data
SF-V99-D4 specifications
SAFE v06 catalogue, printed page 09. Confirm the supplied configuration in your quotation.
Maximum speed is a catalogue rating. Actual output depends on material, setup and handling. Packing dimensions, where listed, describe the shipment.
View the SAFE Catalogue| Model | SF-V99-D4 |
|---|---|
| Machine type | Computerized lockstitch |
| Drive | Direct drive |
| Maximum speed | 5,000 rpm |
| Needle system | DB×1 #9–18 |
| Stitch length | 0–5 mm |
| Catalogue lift range | 5.5–15 mm |
| Automatic backtacking | Yes |
| Automatic presser-foot lifting | Yes, D4 configuration |
| Net / gross weight | 29.5 / 36.6 kg |
| Packing dimensions | 630 × 250 × 550 mm |
Before you choose
Questions about SF-V99-D4
What is the difference between SF-V99-D3 and SF-V99-D4?
The catalogue describes automatic backtacking for both. D4 adds automatic presser-foot lifting, which is relevant when the operator frequently repositions the work.
Can this machine replace a heavy-duty upholstery machine?
Choose according to the actual assembly and feed requirements. Bulky upholstery or difficult layered leather may need a dedicated compound-feed or long-arm machine instead.
Which details are needed for a quotation?
Send the fabric, layer count, seam type, thread, order quantity and destination. Include any required electrical supply and control functions so the configuration can be confirmed.
Ordering & technical support
Prepare a configuration-specific enquiry.
Send the model, material, seam or operation, quantity and destination. For automated equipment, include the workpiece dimensions and current handling steps.
From one machineFactories and dealers welcome
1-year warrantySpare-parts supply available
Remote supportSetup and technical assistance
Pakistan officesKarachi and Faisalabad contacts
