SAFE · Blindstitch & Special Sewing
SF-1430 Neoprene Blindstitch Sewing Machine
The SAFE SF-1430 neoprene blindstitch sewing machine uses a cylinder bed and single-thread chainstitch arrangement. The catalogue highlights neoprene work for diving suits and surfwear, making it a model to assess for shaped garment parts and specialised seam construction.
Product features
Built around the sewing operation.
- 01Cylinder-bed access helps with handling shaped and tubular garment components.
- 02The machine forms a single-thread chainstitch blindstitch as listed in the catalogue.
- 03Neoprene diving-suit and surfwear applications are specifically described for this model.
- 04The listed drive is a 250 W four-pole clutch motor, with a maximum 1,800 stitches per minute.
Applications & catalogue details
Check the material, seam and handling.
- Neoprene diving-suit and surfwear seam operations.
- Shaped or tubular components requiring cylinder-bed access.
- Knitted, cotton or synthetic materials when the required blindstitch seam has been checked.
Send a material or finished-seam sample to confirm the configuration. Catalogue examples illustrate the operation; the required result should be agreed before ordering.
Discuss Your Application
Technical data
SF-1430 specifications
SAFE v06 catalogue, printed page 66. Confirm the supplied configuration in your quotation.
Suitability depends on the neoprene, thickness, joint construction and finishing process. The catalogue does not certify a finished garment or seam as waterproof.
View the SAFE Catalogue| Model | SF-1430 |
|---|---|
| Machine type | Cylinder-bed blindstitch |
| Stitch formation | Single-thread chainstitch |
| Maximum speed | 1,800 stitches/min |
| Stitch ratio | 1:1 |
| Needle system | LW×6T #14 |
| Motor | 250 W, four-pole clutch motor |
| Material category in model table | Heavy material |
Before you choose
Questions about SF-1430
Can SF-1430 be used for wetsuit sewing?
The catalogue specifically identifies neoprene diving-suit and surfwear applications. Send the neoprene type, thickness and seam construction to confirm the required setup.
Will the finished seam be waterproof?
Water resistance depends on the material, joint design and any gluing, sealing or other finishing steps. The machine description alone is not a waterproof-performance guarantee.
How does it differ from SF-101D?
SF-1430 is presented with cylinder-bed access and neoprene applications. SF-101D is a separate blindstitch model for general garment work. Compare the required material and seam, not only the word blindstitch.
Does the standard catalogue specification include a servo motor?
The v06 table lists a 250 W four-pole clutch motor. Any different drive configuration should be separately confirmed in the quotation.
Ordering & technical support
Prepare a configuration-specific enquiry.
Send the model, material, seam or operation, quantity and destination. For automated equipment, include the workpiece dimensions and current handling steps.
From one machineFactories and dealers welcome
1-year warrantySpare-parts supply available
Remote supportSetup and technical assistance
Pakistan officesKarachi and Faisalabad contacts
