Home / Sewing Machines / SF-500-05CB/FT/DD
SAFE · Coverstitch & Elastic Attaching
SF-500-05CB/FT/DD Lace and Elastic Attaching Coverstitch Machine
The SAFE SF-500-05CB/FT/DD coverstitch machine is configured for lace and elastic attaching on light and medium material. The catalogue lists two- or three-needle options and a 3.2–6.4 mm gauge range for matching the seam to the garment edge.
Product features
Built around the sewing operation.
- 01The model is specifically identified for lace and elastic attaching.
- 02Two- or three-needle configurations are listed in the specification table.
- 03The gauge range is 3.2–6.4 mm, subject to the supplied setup.
- 04A maximum 6,000 stitches/min rating is specified for the sewing head.
Applications & catalogue details
Check the material, seam and handling.
- Lace attachment on underwear and related garment edges.
- Elastic attaching on light and medium fabrics.
- Repeated edge-finish operations matched to the selected guide and needle gauge.
Send a material or finished-seam sample to confirm the configuration. Catalogue examples illustrate the operation; the required result should be agreed before ordering.
Discuss Your Application
Technical data
SF-500-05CB/FT/DD specifications
SAFE v06 catalogue, printed page 64. Confirm the supplied configuration in your quotation.
Maximum speed is a catalogue rating. Actual output depends on material, setup and handling. Packing dimensions, where listed, describe the shipment.
View the SAFE Catalogue| Model | SF-500-05CB/FT/DD |
|---|---|
| Operation | Lace and elastic attaching coverstitch |
| Needle system | UY128GAS #11 |
| Needle count | 2 or 3; confirm configuration |
| Needle gauge | 3.2–6.4 mm |
| Material category | Light / medium |
| Presser-foot lift | 5.5 mm |
| Maximum speed | 6,000 stitches/min |
| Automatic foot lifting | Not marked as standard in the catalogue table |
| Automatic thread trimming | Not marked as standard in the catalogue table |
Before you choose
Questions about SF-500-05CB/FT/DD
Does this model have the automatic functions of SF-500-01CB/EUT/DD?
Do not transfer features between suffixes. The table does not mark automatic trimming or foot lifting as standard for SF-500-05CB/FT/DD.
Can it attach both lace and elastic?
These are the stated applications. The guide, feeding arrangement, needle gauge and tension need to be matched to the actual trim and fabric.
What trim information should I provide?
Send the lace or elastic width, stretch, material, desired overlap, fabric layers and photographs or a sample of the finished edge.
Is this the desktop SF-500 blindstitch machine?
No. SF-500-05CB/FT/DD is a coverstitch configuration. The desktop SF-500 is a separate blindstitch machine; use the complete model code when enquiring.
Ordering & technical support
Prepare a configuration-specific enquiry.
Send the model, material, seam or operation, quantity and destination. For automated equipment, include the workpiece dimensions and current handling steps.
From one machineFactories and dealers welcome
1-year warrantySpare-parts supply available
Remote supportSetup and technical assistance
Pakistan officesKarachi and Faisalabad contacts
