SAFE · Elastic Attaching & Overlock
SF-EX-800-18KUT Automatic Elastic Attaching Machine
The SAFE SF-EX-800-18KUT automatic elastic attaching machine is a dedicated option for sewing elastic into garments. Its overlock configuration combines adjustable stitch length and differential feed with a workstation illustrated in the SAFE catalogue.
Product features
Built around the sewing operation.
- 01Dedicated elastic-attaching configuration for repeat garment operations.
- 02Differential feed adjusts from 0.7 to 2 to help match the material and elastic.
- 03The specification lists a 4 mm overedge width and a 0.6–3.8 mm stitch-length range.
- 04A maximum 6,500 rpm rating provides a machine-speed reference for production planning.
Applications & catalogue details
Check the material, seam and handling.
- Elastic attachment to garment openings, subject to sample and fixture review.
- Elastic waistband operations matched to the required finished circumference and elastic width.
- Repeat knit-garment operations where elastic handling is part of the sewing station.
Send a material or finished-seam sample to confirm the configuration. Catalogue examples illustrate the operation; the required result should be agreed before ordering.
Discuss Your Application
Technical data
SF-EX-800-18KUT specifications
SAFE v06 catalogue, printed page 04. Confirm the supplied configuration in your quotation.
Confirm the supplied stitch setup, elastic handling, air supply, table and complete workstation packing in the quotation. Machine speed is not finished garments per hour.
View the SAFE Catalogue| Model | SF-EX-800-18KUT |
|---|---|
| Operation | Automatic elastic attaching |
| Needle system | DC×27 #11 |
| Needles / threads | 2 / 3, as listed in the catalogue |
| Overedge width | 4 mm |
| Stitch length | 0.6–3.8 mm |
| Differential feed ratio | 0.7–2 |
| Presser-foot lift | 6 mm |
| Maximum speed | 6,500 rpm |
Before you choose
Questions about SF-EX-800-18KUT
What should I send for an elastic-attaching quotation?
Send the elastic width and construction, garment fabric, finished circumference, relaxed and stretched measurements, quantity and destination. A seam sample helps confirm feeding and tension.
Is this the same machine as SF-EX-800-4UAT?
No. SF-EX-800-18KUT is listed for elastic attaching; SF-EX-800-4UAT is the neckband-attaching model. Their work-handling arrangements should not be assumed to be interchangeable.
Does 6,500 rpm specify garment output?
No. It is a maximum machine-speed rating. Loading, seam length, material stretch and handling determine the completed output.
Are all handling attachments included?
The catalogue illustration shows a workstation. Ask for an itemised quotation confirming the table, motor, elastic-handling components and any air-supply requirements.
Ordering & technical support
Prepare a configuration-specific enquiry.
Send the model, material, seam or operation, quantity and destination. For automated equipment, include the workpiece dimensions and current handling steps.
From one machineFactories and dealers welcome
1-year warrantySpare-parts supply available
Remote supportSetup and technical assistance
Pakistan officesKarachi and Faisalabad contacts
