Home / Sewing Machines / SF-B-2000C-UTC
SAFE · Belt Loop & Chainstitch
SF-B-2000C-UTC Belt Loop Making Machine
The SAFE SF-B-2000C-UTC belt loop making machine uses a flat-bed double-chainstitch arrangement to produce belt-loop strips. The catalogue lists 8–18 mm belt-loop width options and an optional tape cutter with adjustable loop length.
Product features
Built around the sewing operation.
- 01A flat-bed layout is dedicated to producing belt-loop strips.
- 02The specification lists two needles and three threads.
- 03Belt-loop widths from 8 to 18 mm are described as options to confirm with the chosen setup.
- 04An automatic tape cutter is optional; the required cut length should be specified in the order.
Applications & catalogue details
Check the material, seam and handling.
- Making belt-loop strips for trousers and jeans.
- Repeated narrow-strip chainstitch operations matched to the folding setup.
- Belt-loop preparation before a separate attaching or bartacking operation.
Send a material or finished-seam sample to confirm the configuration. Catalogue examples illustrate the operation; the required result should be agreed before ordering.
Discuss Your Application
Technical data
SF-B-2000C-UTC specifications
SAFE v06 catalogue, printed page 51. Confirm the supplied configuration in your quotation.
Maximum speed is a catalogue rating. Actual output depends on material, setup and handling. Packing dimensions, where listed, describe the shipment.
View the SAFE Catalogue| Model | SF-B-2000C-UTC |
|---|---|
| Machine type | Flat-bed double-chainstitch belt-loop maker |
| Needles / threads | 2 / 3 |
| Needle system | UY×128GAS #14–18 |
| Needle gauge | 1/4 inch |
| Belt-loop width options | 8–18 mm; confirm supplied setup |
| Presser-foot lift | 8 mm |
| Maximum speed | 3,000 rpm |
| Automatic tape cutter | Optional |
Before you choose
Questions about SF-B-2000C-UTC
Does this machine attach belt loops to the trousers?
It makes the belt-loop strip. Attaching the finished loops to a waistband is a separate operation requiring suitable sewing or bartacking equipment.
Is the automatic cutter included as standard?
The catalogue labels the tape cutter as optional. Confirm cutter inclusion and the adjustable length range in the quotation.
Can one setup produce every width from 8 to 18 mm?
Do not assume this. The catalogue describes width options; the supplied folder, needle gauge and cutter must be matched to the required strip and finished width.
What samples are helpful before ordering?
Send the fabric, cut-strip width, finished loop width, cut length, seam sample and expected production quantity.
Ordering & technical support
Prepare a configuration-specific enquiry.
Send the model, material, seam or operation, quantity and destination. For automated equipment, include the workpiece dimensions and current handling steps.
From one machineFactories and dealers welcome
1-year warrantySpare-parts supply available
Remote supportSetup and technical assistance
Pakistan officesKarachi and Faisalabad contacts
